Features:High and low pressure pump, can supply oil when low pressure large flow and highpressure small flow.
Application:Mainly used in hydraulic power unit(minitype),hydraulic tools ,medical appliances ,machine tools ,machines.
Outline dimensions
Specification
| No. | Type | Displacement(ml/r) | Pressure (MPa) | Rotating Speed (r/min) | Oil Viscosity v50 (Cst) | Oil Pollution (Tag) | Volumetic Efficiency (%) | |
|---|---|---|---|---|---|---|---|---|
| Rated | Max | |||||||
| 1 | CBMSL1-G0.75/*Z | 0.75/* | 21 | 28 | 500~3000 | 7~70 | 14/11~19/16 | 90 |
| 2 | CBMSL1-G1/*Z | 1/* | 21 | 28 | 500~3000 | 7~70 | 14/11~19/16 | 90 |
| 3 | CBMSL1-G1.3/*Z | 1.3/* | 21 | 28 | 500~3000 | 7~70 | 14/11~19/16 | 92 |
| 4 | CBMSL1-G1.6/*Z | 1.6/* | 21 | 28 | 500~3000 | 7~70 | 14/11~19/16 | 92 |
| 5 | CBMSL1-G1.9/*Z | 1.9/* | 21 | 28 | 500~3000 | 7~70 | 14/11~19/16 | 92 |
| 6 | CBMSL1-E2.5/*Z | 2.5/* | 12 | 16 | 500~2000 | 7~70 | 14/11~19/16 | 92 |
| 7 | CBMSL1-E3/*Z | 3/* | 12 | 16 | 500~2000 | 7~70 | 14/11~19/16 | 92 |
| 8 | CBMSL1-E3.2/*Z | 3.2/* | 12 | 16 | 500~2000 | 7~70 | 14/11~19/16 | 92 |
| 9 | CBMSL1-D4/*Z | 4/* | 10 | 12 | 500~1500 | 7~70 | 14/11~19/16 | 92 |
| 10 | CBMSL1-D4.5/*Z | 4.5/* | 10 | 12 | 500~1500 | 7~70 | 14/11~19/16 | 92 |
| 11 | CBMSL1-D6/*Z | 6/* | 10 | 12 | 500~1500 | 7~70 | 14/11~19/16 | 92 |
| 12 | CBMSL1-D6.9/*Z | 6.9/* | 10 | 12 | 500~1500 | 7~70 | 14/11~19/16 | 92 |
| 13 | CBMSL1-D7.8/*Z | 7.8/* | 10 | 12 | 500~1500 | 7~70 | 14/11~19/16 | 92 |
