Features:Pressure compensation pump, high working pressure, small-displacement.
Application:Mainly used in hydraulic power unit(minitype),hydraulic tools ,medical appliances ,machine tools ,machines, snow scraper and so on.
Outline dimensions
Specification
| No. | Type | Displacement(ml/r) | Pressure (MPa) | Rotating Speed (r/min) | Oil Viscosity v50 (Cst) | Oil Pollution (Tag) | Volumetic Efficiency (%) | L (mm) | |
|---|---|---|---|---|---|---|---|---|---|
| Rated | Max | ||||||||
| 1 | CBL1-G0.75F | 0.75 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 90 | 117.5 |
| 2 | CBL1-G1F | 1.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 90 | 118.1 |
| 3 | CBL1-G1.18F | 1.18 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 92 | 118.4 |
| 4 | CBL1-G1.5F | 1.50 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 92 | 119.5 |
| 5 | CBL1-G2F | 2.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 92 | 121.5 |
| 6 | CBL1-G2.5F | 2.50 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 92 | 123.4 |
| 7 | CBL1-G3F | 3.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 92 | 124.5 |
| 8 | CBL1-G3.3F | 3.30 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 92 | 125.6 |
| 9 | CBL1-G4F | 4.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 92 | 128.7 |
