Features:Fixed interval pump, high working pressure, small-displacement.
Application:Mainly used in hydraulic power unit(minitype),hydraulic tools ,medical appliances,machine tools ,machines, snow scraper and so on.
Outline dimensions
Specification
| No. | Type | Displacement(ml/r) | Pressure (MPa) | Rotating Speed (r/min) | Oil Viscosity v50 (Cst) | Oil Pollution (Tag) | Volumetic Efficiency (%) | L (mm) | |
|---|---|---|---|---|---|---|---|---|---|
| Rated | Max | ||||||||
| 1 | CBL-G0.75 | 0.75 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 65 | 78.6 |
| 2 | CBL-G1 | 1.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 65 | 79.2 |
| 3 | CBL-G1.18 | 1.18 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 68 | 79.5 |
| 4 | CBL-G1.5 | 1.50 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 68 | 80.6 |
| 5 | CBL-G2 | 2.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 72 | 81.6 |
| 6 | CBL-G2.5 | 2.50 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 72 | 83.5 |
| 7 | CBL-G3 | 3.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 76 | 84.6 |
| 8 | CBL-G3.3 | 3.30 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 76 | 85.7 |
| 9 | CBL-G4 | 4.00 | 21 | 27.5 | 500~4000 | 7~70 | 14/11~19/16 | 78 | 88.8 |
