Features:Pressure compensation pump, high working pressure, small-displacement, small appearance.
Application:Mainly used in hydraulic power unit(minitype), hydraulic tools, medical appliances,machine tools, machines.
Outline dimensions
Specification
| No. | Type | Displacement (ml/r) | Pressure(Mpa) | Rotating Speed (r/mm) | Oil Viscosity v50 (Cst) | Oil Pollution (Tag) | Volumetric Efficiency (%) | K1 Inlet | K2 Outlet | |
|---|---|---|---|---|---|---|---|---|---|---|
| Rated | Max | |||||||||
| 1 | CBKL-G1.6F | 1.60 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 90 | SAE9/6-18 | SAE9/6-18 |
| 2 | CBKL-G2F | 2.0 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 90 | SAE9/6-18 | SAE9/6-18 |
| 3 | CBKL-G2.5F | 2.5 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 92 | SAE9/6-18 | SAE9/6-18 |
| 4 | CBKL-G3F | 3.0 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 92 | SAE3/4-16 | SAE9/6-18 |
| 5 | CBKL-G3.3F | 3.3 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 92 | SAE3/4-16 | SAE9/6-18 |
| 6 | CBKL-G4F | 4.0 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 92 | SAE3/4-16 | SAE9/6-18 |
| 7 | CBKL-G4.2F | 4.2 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 92 | SAE7/8-14 | SAE3/4-16 |
| 8 | CBKL-G4.8F | 4.8 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 92 | SAE7/8-14 | SAE3/4-16 |
| 9 | CBKL-G5F | 5.0 | 21 | 27.5 | 500～4000 | 7～70 | 14/11～19/16 | 92 | SAE7/8-14 | SAE3/4-16 |
| 10 | CBKL-G5.5F | 5.5 | 16 | 21 | 500～3000 | 7～70 | 14/11～19/16 | 92 | SAE7/8-14 | SAE3/4-16 |
| 11 | CBKL-G5.8F | 5.8 | 16 | 21 | 500～3000 | 7～70 | 14/11～19/16 | 92 | SAE7/8-14 | SAE3/4-16 |
| 12 | CBKL-G6.8F | 6.8 | 16 | 21 | 500～3000 | 7～70 | 14/11～19/16 | 92 | SAE7/8-14 | SAE3/4-16 |
