Features:Pressure compensation Hi/low pump, high working pressure, small-displacement.
Application:Mainly used in hydraulic power unit(minitype),hydraulic tools, medical appliances,machine tools, machines.
Outline dimensions
Specification
| No. | Type | Displacement (ml/r) | Pressure(Mpa) | Rotating Speed (r/mm) | Oil Viscosity v50 (Cst) | Oil Pollution (Tag) | Volumetric Efficiency (%) | A (mm) | B (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|
| Rated | Max | |||||||||
| 1 | CBK1SL-G0.17/2F | 0.17/2 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 90 | 30.8 | 128 |
| 2 | CBK1SL-G0.25/3F | 0.25/3 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 90 | 33.4 | 134.3 |
| 3 | CBK1SL-G0.35/6.7F | 0.35/6.7 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 33.4 | 134.8 |
| 4 | CBK1SL-G0.45/3F | 0.45/3 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 43.2 | 154.8 |
| 5 | CBK1SL-G0.5/6.7F | 0.5/6.7 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 30.8 | 130.8 |
| 6 | CBK1SL-G0.6/2F | 0.6/2 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 30.8 | 138.3 |
| 7 | CBK1SL-G0.75/3F | 0.75/3 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 33.4 | 157.8 |
| 8 | CBK1SL-G0.84/6.7F | 0.84/6.7 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 43.2 | 157.8 |
| 9 | CBK1SL-G1/2F | 1/2 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 30.8 | 134.3 |
| 10 | CBK1SL-G1.2/3F | 1.2/3 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 33.4 | 142.3 |
| 11 | CBK1SL-G1.57/6.7F | 1.5/6.7 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 43.2 | 163.8 |
| 12 | CBK1SL-G1.7/3F | 1.7/3 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 33.4 | 146.6 |
| 13 | CBK1SL-G2/6.7F | 2/6.7 | 21 | 18 | 1500～4000 | 7～70 | 14/11～19/16 | 92 | 43.2 | 168.3 |
