Features:Pressure compensation pump, high working pressure, medium displacement.
Application:Mainly used in engineering machinery, mining machinery, building machineryand so on.
Outline dimensions
Specification
| No. | Type | Displacement (L/min) | Pressure(Mpa) | Rotating Speed (r/mm) | Oil Viscosity v50 (Cst) | Oil Temperature (℃) | Oil Pollution (Tag) | Volumetric Efficiency (%) | L (mm) | H (mm) | C (mm) | d (mm) | d1 (mm) | 4- (mm) | D (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | CB-32 | 32 | 16 | 2000 | 7～70 | -10～70 | 14/11～19/16 | 90 | 186 | 48 | 68 | 24 | 16 | M8 | 65 |
| 2 | CB-46 | 46 | 16 | 2000 | 7～70 | -10～70 | 14/11～19/16 | 90 | 195 | 51 | 74 | 30 | 22 | M8 | 76 |
| 3 | CB-50 | 50 | 16 | 2000 | 7～70 | -10～70 | 14/11～19/16 | 90 | 200 | 51 | 74 | 30 | 22 | M8 | 76 |
| 4 | CB-63 | 63 | 16 | 2000 | 7～70 | -10～70 | 14/11～19/16 | 90 | 215 | 51 | 74 | 30 | 22 | M8 | 76 |
