Features:Pressure compensation pump, high working pressure, medium displacement.
Application:Mainly used in engineering machinery, mining machinery, building machineryand so on.
Outline dimensions
Specification
| No. | Type | Displacement(ml/r) | Pressure (MPa) | Rotating Speed (r/min) | Oil Viscosity v50 (Cst) | Oil Pollution (Tag) | Oil Temperature (℃) | Volumetic Efficiency (%) | K1 Port Size | K2 Prot Size | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated | Max | ||||||||||
| 1 | CB-FA10F | 10 | 14 | 18 | 500~2500 | 7~70 | 14/11~19/16 | -10~70 | 91 | M33*2 | M27*2 |
| 2 | CB-FA16F | 16 | 14 | 18 | 500~2500 | 7~70 | 14/11~19/16 | -10~70 | 91 | M33*2 | M27*2 |
| 3 | CB-FA18F | 18 | 14 | 18 | 500~2500 | 7~70 | 14/11~19/16 | -10~70 | 92 | M33*2 | M27*2 |
| 4 | CB-FA25F | 25 | 14 | 18 | 500~2500 | 7~70 | 14/11~19/16 | -10~70 | 92 | M33*2 | M27*2 |
| 5 | CB-FA32F | 32 | 14 | 18 | 500~2500 | 7~70 | 14/11~19/16 | -10~70 | 92 | M33*2 | M27*2 |
| 6 | CB-FA40F | 40 | 14 | 18 | 500~2500 | 7~70 | 14/11~19/16 | -10~70 | 92 | M33*2 | M27*2 |
